GRGTEST invested one million yuan to purchase the RS105 electromagnetic pulse testing system.Recently passed the acceptance and put into use. GRGTEST has become one of the few testing institutions in the country with the system, possessing all the testing capabilities of GJB 151B-2013.
RS105 Electromagnetic Pulse Testing System
The system meets the relevant test requirements for the RS105 transient electromagnetic field radiation sensitivity project in the standards GJB 151A-97, GJB 152A-97, GJB 151B-2013, and MIL-STD-461E/F/G, and can apply a maximum pulse electric field of 100kV/m to the test sample to test its reliability in a strong pulse electric field environment.
The overall technical specifications of the simulator are as follows：
1. Peak field strength: continuously adjustable from 5kV/m to 100kV/m
2. Effective experimental space: 1m × 1m × 0.7m
3. Electric field pulse front (10%~90%): 2.5ns ± 0.5ns
4. Half peak pulse width: 23ns ± 5ns
GRGTEST can provide full lifecycle technical solutions for electromagnetic compatibility design, simulation, testing, and rectification for special industry enterprises, research institutes, and customers in aviation, automotive, rail transit, medical equipment, and other fields.
The laboratory is also equipped with a portable anti-interference/emission testing system, which can meet the requirements of field testing. The experiment covers GJB 151/2A-97, GJB 151B-2013 (covering all 21 standards) GJB 1389A-2005,GJB 1389B-2022,GJB 8848-2016,GJB 181-86,GJB 181A-2003,GJB 181B-2012,HB20326.2～8-2016,HB 6167.18-2014,RTCA/DO-160 Waiting for standard abilities.
